PavePal P900
Partner roboticsBattery robot that spreads adhesive and sets full floor tiles in one pass from a tablet layout18 deployments · 6 countries
Image: Fangshi RoboticsStone Tile Laying Robot
Battery robot with a 7-axis arm that beds and sets stone floor slabs up to 120 kg
- 2
- Deployments
- 1
- Companies that ran it
How it works on your site
Fangshi Robotics' Stone Tile Laying Robot is a battery-powered floor paving robot: a 7-axis heavy-load arm on an omnidirectional wheeled chassis, rated by Fangshi for marble, granite and travertine slabs up to 120 kg each. On board it spreads a dry sand-mortar bed, back-coats each slab with cement slurry or tile adhesive and sets it by visual servoing; people do the substrate water spraying, reference lines and CAD setup beforehand, and the Hefei airport job ran a three-person robot crew. Product status is unknown.
Tile Setting (Ceramic/Stone)
Image: Fangshi Robotics
Field outcomes
-
Image: Fangshi Robotics
Who has run it
2 deployments · 1 company · 1 country
Will it work on your site
- Site Preparation
- Water spraying, reference lines and CAD setupManual pre-work before the robot runs
- Control Interface
- Tablet appIntegrated construction robot controller
- BIM/CAD Requirements
- No BIM input statedCAD setup listed as pre-work
- Fleet Management
- Fleet management not stated
- Payload Capacity
- 120 kg per slab (vendor spec)Heaviest case-reported slab 77 kg (Shenzhen)
As the maker states it.
